Develop ineo 161 - Misfeed at the Paper Separating Section

Field Service Ver. 1.0 Apr. 2005 14. Jam Display
125
ineo 161 ineo 210
Troubleshooting
14.3.6 Misfeed at the Paper Separating Section
A. Detection Timing
B. Action
Type Description
Paper separating
section misfeed
detection
• The Exit Paper Sensor (PC3) is not blocked even after the lapse of a given
period of time after the paper has unblocked the Synchronizing Roller Sensor
(PC1).
• The Synchronizing Roller Sensor (PC1) is not blocked even after the lapse of a
given period of time after the paper has unblocked the Synchronizing Roller
Sensor (PC1).
• The Synchronizing Roller Sensor (PC1) is blocked before the lapse of a given
period of time after the paper has unblocked the Synchronizing Roller Sensor
(PC1).
Paper left at the
paper separating
section
• The Synchronizing Roller Sensor (PC1) is unblocked at timing when the Power
Switch is turned ON, the cover is opened and closed, or a paper misfeed or
malfunction is reset.
Relevant Electrical Components
Synchronizing Roller Sensor (PC1)
Exit Paper Sensor (PC3)
Master Board (PWB-A)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1 Initial checks – – –
2 PC1 sensor check
☞ 115 PWB-A PJ17A-3 (ON)
3 PC3 sensor check
☞ 115 PWB-A PJ15A-3 (ON)
4 Replace PWB-A – – –
