14. Jam Display Field Service Ver. 1.0 Apr. 2005
128
ineo 161
ineo 210
Troubleshooting
14.3.9 Misfeed at the Document Transport Section
(When the optional Automatic Document Feeder DF-502 is mounted)
A. Detection Timing
B. Action
Type Description
Document
transport section
misfeed detection
• The Registration Sensor (PC3/AF) is not blocked even after the lapse of a given
period of time after the Main Motor (M1/AF) has been energized.
Document left in
the document
transport section
• The Registration Sensor (PC3/AF) is blocked at timing when the Power Switch
is turned ON, the cover is opened and closed, or a paper misfeed or malfunc-
tion is reset.
Relevant Electrical Components
Main Motor (M1/AF)
Registration Sensor (PC3/AF)
Interface Board (PWB/AF)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1 Initial checks – – –
2 M1/AF operation check
☞ 117 –
3 PC3/AF sensor check
☞ 115 PWB/AF CN2/AF-6 (ON)
4 Replace PWB/AF – – –
To Next Page
