15.3.6 C0210: Abnormal Image Transfer Voltage
A. Detection Timing
B. Action
Trouble Code Description
C0210
• The image transfer voltage remains more than 100 V for a continuous given
period of time while the PC Drum remains stationary.
Relevant Electrical Components
Image Transfer Roller
High Voltage Unit (HV1)
Master Board (PWB-A)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1
Check the Image Transfer Roller for
installation.
–– –
2 Change HV1. – – –
3 Change PWB-A. – – –
