Field Service Ver. 1.0 Apr. 2005 13. Introduction
115
ineo 161
ineo 210
Troubleshooting
Troubleshooting
13. Introduction
• Information required for troubleshooting and steps that must be performed are described
in this chapter.
13.1 Electrical Components Check Procedure
• If a paper misfeed or malfunction occurs, perform the following operations to check the
condition of the electrical components.
13.1.1 Sensor
Step Check Result Action
1
Does the input signal of the control board change when the
sensor light is interrupted? (H → L, L → H)
NO Replace the sensor.
YES
Replace the control
board.
4025T520AA
4025T521AA
To Next Page
