Develop ineo 161 - 17.2 Solution; Image Reading Section: Blank Copy

Field Service Ver. 1.0 Apr. 2005 17. Image quality problem
155
ineo 161 ineo 210
Troubleshooting
17.2 Solution
17.2.1 Image Reading Section: Blank copy
A. Typical Faulty Images
B. Troubleshooting Procedure
4011T035AA
Step Check Result Action
1 CCD Board (PWB-J) connector is loose. YES • Reconnect.
2 Control Board (PWB-C) connector is loose.
YES • Reconnect.
NO
• Change Control Board
(PWB-C/C).
• Change Master Board
(PWB-A).
