Field Service Ver. 1.0 Apr. 2005 15. Malfunction code
135
ineo 161 ineo 210
Troubleshooting
15.3 Solution
15.3.1 C0000: Main Motor malfunction
A. Detection Timing
B. Action
Trouble Code Description
C0000
• The Main Motor (M1) Lock signal remains HIGH for a continuous 1-sec. period
at any time 1 sec. after the Main Motor has started turning.
Relevant Electrical Components
Main Motor (M1) Master Board (PWB-A)
Power Supply Unit (PU1)
Step Operations
Ref.
Page
WIRING DIAGRAM
Control signal
Location
(Electrical
Components)
1
Check M1 connectors for proper con-
nection and correct as necessary.
–– –
2
Check M1 for correct drive coupling
and correct as necessary.
–– –
3 M1 operation check.
☞ 117 –I-14
4 Change PWB-A. – – –
5 Change PU1. – – –
