6. Other Field Service Ver. 1.0 Apr. 2005
32
ineo 161 ineo 210
Maintenance
No. Part Name Removal Procedure
12 Right Rear Cover
Remove the Upper Rear Cover. → Remove three screws. →
Remove the Right Rear Cover.
13 Left Rear Cover
Remove the Upper Rear Cover. → Remove four screws. →
Remove the Left Rear Cover.
14 Upper Rear Cover Remove four screws. → Remove the Upper Rear Cover.
15 Rear Cover
Remove nine screws. → Remove the Rear Cover.
NOTE
When the Rear Cover is to be installed, make sure of type of
screw.
(9735-0306-14 × 8 Screw, 9770-0308-14 × 1 Screw)
16 Rear Right Cover Remove two screws. → Remove the Rear Right Cover.
17 Right Cover
Remove the Upper Rear Cover. → Remove the Front Cover. →
Remove four screws. → Remove the Right Cover.
4035D048AB
17
13
15
12
14
16
