TRUCK
FRAME
OR
BED SUPPORT
1/4
TH
BO
OT
FA
DE
OPERATOR’S MANUAL
Figure 9
Securing Member with Bolts
TRUCK
FRAME
OR BED
SUPPORT
1/4 x 20 BOLT
1/4 FLAT WASHER
1/4 NUT
1/4 SPLIT
LOCKWASHER
1/4 FLAT WASHER
1/4 NUT
x 20
READED "U"
T OR
HER
TENING
VICE
1/4 SPLIT LOCKWASHER
5.
To tie strap the module to a frame:
–
Use one long tie strap to loop around the member body and
through both mounting holes as illustrated in Figure 9.
–
If necessary, drill mounting holes following the procedure described
above.
–
Securely tighten tie strap.
–
Install a second tie strap toward the label end of the enclosure for
additional support.
Flex4 Pro
TM
Control System
6010541 Rev A
COMPONENT OVERVIEW / 13
