MAINTENANCE 10
AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A] 115
ATTENTION
When fitting a new or repaired tyre, use a
valve adapter of spring type with distant
pressure gauge that allows the operator
to stay well away from the tyre during
inflation.
Use a safety cage.
10.14.3.1 - Tyre pressure: Inspection
Figure: 150578-1
Verify and adjust the pressure of the front and rear
tyres.
Check that the tread and the sides are not damaged.
Connect a pressure gauge to the tyre valve and verify
that the inflation pressure is correct.
10.14.3.2 - Tires filled with urethane
NOTE
Tires filling with urethane is an optional
accessory.
Consult your dealer in case of doubts or
information on your vehicle.
DANGER
It is not permitted to fit tires inflated with
polyurethane foam unless authorized by
the manufacturer.
With tires filled with urethane it is forbidden to
travel on the road.
ATTENTION
The maximum permitted speed with tires filled
with urethane is 20 km/h (12.4 mph).
10.14.3.3 - Pneumatic symbols key
Icon Description
Tyre dimensions
Indicates the tyre pressure.
Tread pattern
Indicates the design with which the tyre tread is
carved.
Load index and Speed index
The load index corresponds to the maximum
load that the tyre can support.
The speed index indicates the maximum speed
at which the tyre can bear the weight
corresponding to its load index.
Tyre pressure
For most vehicle models, tyre pressure is the
same for all wheels.
Front axle tyre pressure
For some vehicle models, the tyres must be
inflated with different pressures between the
front axle and the rear axle.
Rear axle tyre pressure
For some vehicle models, the tyres must be
inflated with different pressures between the
front axle and the rear axle.
10.15 - Drum maintenance
Drum gearbox oil: Check and replacement
Figure: 170108-1
