MAINTENANCE
118 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]
10.16.3 - Work light *
NOTE
* The work light is an optional accessory.
1
2
Figure: 150305-1
Work light bulb replacement
To access the bulbs (fig. 150305-1):
• Prepare the vehicle in the maintenance position.
• Turn off the battery isolation switch to disconnect
power to the electrical system.
• Remove the power connector at the back of the
light “1”.
• Press the connector socket on the light “2”.
• Turn the socket, keeping it pressed, to release it
from the lock.
Perform the same procedure in reverse order to insert
the new bulb.
10.16.4 - Led work light*
NOTE
* The LED work light is an optional accessory.
Figure: 150303-1
The LED work light (fig. 150303-1) does not require
maintenance.
10.17 - Window washer fluid
tank
Figure: 150466-1
The washer fluid tank is located on the right side of the
seat “1” (fig. 150466-1).
To add liquid to the tank:
• Remove the filling cap.
• Add washing fluid to fill the tank.
• Put back the cap.
ATTENTION
During the winter, mix antifreeze fluid to the
water.
