The shovel must be raised completely and fastened
with the relative chain when driving on the road.
Make sure the loading shovel is not fastened with the
safety chain (fig. 161201-2) before moving the loading
shovel.
WARNING
Do not lift the rear wheels of the vehicle while the
shovel is in the loading phase or when
maintenance is being performed.
Do not lower the loading shovel when the drum is
raised.
Do not use the loading shovel to load the drum
turned to one side as there is a risk of the vehicle
overturning on the side. Only use the loading
shovel when the drum is aligned with the vehicle.
7.8 - Drum lifting control lever
Move the lever “1” (fig. 161205-1)
as follows to lower the drum:
• Push the lever towards
side "A" to lower the
drum, bringing it back to
transport mode
• Pull the lever towards side
"B" to lift the drum,
thereby facilitating the
unloading procedure
Release the lever for it to return to
the central idle position and the
movement will be stopped; the
drum will then stop in the
position reached.
161205-1
WARNING
The drum must be completely lowered when
driving on the road.
The drum must be completely lowered during the
loading phase.
Do not raise the drum while the loading shovel is
lowered. There lies the risk of the loading shovel
being damaged or broken.
7.9 - Mixing/Unloading Button
*
NOTE
* Attachments available for some vehicle models.
Figure: 161212-1
The mixing/unloading button “1” (fig. 161212-1)
allows the drum to rotate and consequently mix or
unload the contents of the drum.
• Press the button on side "A" to rotate the drum
for it to unload its contents.
• Press the button on side "B" to rotate the drum
for it to mix its contents.
Press the button on the same side repeatedly or keep
it pressed to increase the speed of rotation.
Simply press the button on the opposite side to
decrease the speed or stop rotation.
