SAFETY REGULATIONS
46 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]
• After the unloading is complete, return the drum
to the transport position (fully down) and set the
drum rotation in the mixing direction.
NOTE! The drum lifting and lowering function is
only available on models L3500 and L4700.
After the unloading phase, clean the drum. For the
correct drum washing procedures refer to the "Drum
cleaning" chapter.
4.13.3 - Drum unloading in
movement
Figure: 170107-1
To successfully unload the drum of the machine
perform the following procedures:
• Fully lift the loading shovel
• Make sure that the drum is completely lowered
• Keep the drum in rotation in the mixing direction
• Place the gear lever in neutral ("N")
• Engage the parking brake
• Get off the machine and move the unloading
chute to the right side of the machine, so that it
can be visible from the cab
• Install the extension chute (if present)
• Reverse the driving seat
• Slowly move the machine to the unloading point
• Carry out the unloading operation setting the
drum rotation in the unloading direction
• Place the gear lever in "F" and move slowly
• Use the controls in the cab to lift the drum to
facilitate unloading all the mixture
• After the unloading is complete, stop the
machine travel, return the drum to the transport
position (fully down) and set the drum rotation in
the mixing direction
CAUTION!To move safety with reversed driver's
seat, use the help of a person on the ground for
signalling.
NOTE! The drum lifting and lowering function is
only available on some models.
After the unloading phase, clean the drum. For the
correct drum washing procedures refer to the "Drum
cleaning" chapter.
