Dieci s.r.l. Maintenance |
AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A] 123 / 199
10.20.2 - Torque specifications - fasteners: Coarse pitch
Coefficient of
friction
4.8 5.8 6.8 8.8 10.9 12.9
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
M3
0.10 1220 0.54 1525 0.68 1830 0.82 2440 1.09 3431 1.53 4117 1.84
0.14 1126 0.60 1407 0.83 1689 1.00 2252 1.34 3167 1.88 3800 2.26
M3.5
0.10 1638 0.84 2048 1.05 2457 1.26 3276 1.68 4608 2.36 5529 2.84
0.14 1511 1.03 1889 1.28 2267 1.54 3023 2.05 4251 2.89 5101 3.47
M4
0.10 2115 1.25 2644 1.56 3173 1.88 4231 2.50 5950 3.52 7140 4.22
0.14 1951 1.53 2439 1.91 2926 2.29 3902 3.06 5487 4.30 6584 5.16
M5
0.10 3462 2.46 4327 3.08 5192 3.70 6923 4.93 9736 6.93 11683 8.32
0.14 3197 3.02 3996 3.78 4795 4.53 6394 6.04 8991 8.50 10789 10.20
M6
0.10 4875 4.24 6093 5.30 7312 6.35 9749 8.47 13710 11.92 16452 14.30
0.14 4499 5.19 5624 6.48 6749 7.78 8998 10.37 12654 14.59 15184 17.51
M7
0.10 7135 6.97 8918 8.71 10702 10.45 14269 13.94 20066 19.60 24079 23.52
0.14 6600 8.60 8250 10.76 9899 12.90 13199 17.21 18561 24.20 22274 29.04
M8
0.10 8947 10.20 11184 12.75 13421 15.30 17894 20.41 25164 28.70 30197 34.44
0.14 8266 12.54 10332 15.67 12398 18.80 16531 25.07 23247 35.26 27897 42.31
M10
0.10 14245 20.11 17806 25.14 21367 30.16 28489 40.22 40063 56.56 48075 67.87
0.14 13167 24.76 16459 30.95 19751 31.14 26335 49.52 37033 69.64 44440 83.56
M12
0.10 20767 34.43 25958 43.03 31150 51.64 41533 68.86 58406 96.83 70087 116.20
0.14 19204 42.42 24005 53.03 28806 63.63 38408 84.84 54011 119.31 64814 143.17
M14
0.10 28390 54.77 35487 68.46 42585 82.15 56780 109.53 79847 154.03 95816 184.84
0.14 26261 67.56 32827 84.45 39392 101.34 52522 135.13 73860 190.02 88632 228.03
M16
0.10 39242 85.14 49053 106.43 58863 127.72 78484 170.29 110369 239.47 132442 287.36
0.14 36364 105.80 45455 132.26 54546 158.71 72729 211.61 102274 297.58 122729 357.09
M18
0.10 47533 117.48 59416 146.85 71300 176.22 95066 234.96 133687 330.41 160424 396.49
0.14 43986 145.16 54983 181.45 65979 217.74 87972 290.32 123711 402.26 148453 489.92
M20
0.10 61238 166.08 76548 207.61 91857 249.13 122476 332.17 172232 467.11 206678 560.54
