| Maintenance Dieci s.r.l. 124 / 199 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]
Coefficient of
friction
4.8 5.8 6.8 8.8 10.9 12.9
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
0.14 56747 206.39 70934 257.98 85121 309.58 113494 412.78 159601 580.47 191522 696.56
M22
0.10 76305 227.22 95382 284.02 114458 340.82 152610 454.43 214608 639.05 257530 766.85
0.14 70792 283.79 88490 352.74 106188 425.69 141584 567.58 199102 798.16 238923 957.80
M24
0.10 88232 287.16 110291 358.94 132349 430.73 176465 574.31 248154 807.63 297784 969.15
0.14 81762 356.84 102202 446.05 122643 535.26 163524 713.68 229955 1003.61 275946 1204.33
M27
0.10 115779 420.40 144724 525.05 173668 930.06 231558 840.08 325628 1181.36 390753 1417.63
0.14 107442 525.08 134302 656.35 161162 787.62 214883 1050.16 302179 1476.79 362615 1772.15
M30
0.10 141000 572.83 176249 716.03 211499 859.24 281999 1145.65 396561 1611.08 475873 1933.29
0.14 130771 714.49 163463 893.11 196156 1071.73 261541 1428.97 367792 2009.49 441351 2411.39
