VEHICLE DESCRIPTION 5
AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A] 49
5.2 - Right side components description
Figure: 161171-1 - Right side description
1 Cab 2 Door
3 Ladder for climbing on 4 Chassis
5 Front lights 6 Rear lights
7 Water tank 8 Front axle
9 Rear axle 10 Wheel
11 Epicycloidal reduction gear 12 Turning frame
13 Drum 14 Loading shovel
15 Unloading chute 16 Chute extension (optional)
17 Unloading chute pump 18 Emergency stop button
19 External drum rotation controls 20 Water pump
21 External water pump controls 22 Fuel tank filler cap
23 Water tank filler cap 24 Anchoring or tow hitch
25 Drum opening pump (optional) 26 Drum opening pump (optional)
