6.2.2 - Truck mixer symbols legend
The symbols listed below have been used to describe actions and functions of the machine and of its components,
for an easier and immediate recognition during the working phases.
If in doubt, contact your agent or dealer.
Symbol Meaning
Drum lowering
Drum lifting
Drum rotation for mixture
Drum rotation for unloading
Drum rotation speed
Drum rotation towards the right side of the machine
Drum rotation towards the left side of the machine
Loading shovel lowering
Loading shovel lifting
Loading shovel down tilting
