Dieci s.r.l. Maintenance | AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A] 121 / 199
10.20 - Torque specifications - fasteners
10.20.1 - Torque specifications - fasteners: Fine pitch
Coefficient of
friction
4.8 5.8 6.8 8.8 10.9 12.9
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
M8
0.10 9798 10.87 12248 13.59 14697 16.31 19596 21.75 27557 30.58 33069 36.70
0.14 9080 13.53 11349 16.91 13619 20.29 18159 27.05 25536 38.04 30643 45.65
M10
0.10 15297 21.13 19121 26.41 22945 31.69 30594 42.25 43023 59.42 51627 71.30
0.14 14175 26.27 17719 32.84 21263 39.41 28350 52.55 39867 73.89 47841 88.67
M10
0.10 16384 22.12 20480 27.66 24575 33.19 32767 44.25 46079 62.23 55295 74.67
0.14 15222 27.80 19027 34.75 22833 41.70 30443 55.61 42811 78.20 51373 93.84
M12
0.10 22021 35.83 27526 44.79 33031 53.75 44041 71.67 61933 100.78 74320 120.94
0.14 20406 44.53 25507 55.66 30609 66.79 40812 89.06 57391 125.24 68870 150.29
M12
0.10 23334 37.26 29167 46.57 35001 55.88 46667 74.51 65626 104.78 78751 125.74
0.14 21669 46.70 27087 58.38 32504 70.06 43338 93.41 60945 131.36 73134 157.63
M14
0.10 31610 59.04 39513 73.80 47415 88.57 63220 118.09 88903 166.06 106684 199.27
0.14 29346 73.92 36682 92.40 44019 110.89 58692 147.85 82535 207.91 99043 249.49
M16
0.10 42581 89.78 53227 112.23 63872 134.67 85163 179.56 119760 252.51 143712 303.02
0.14 39588 113.06 49485 141.32 59382 169.59 79176 226.12 111341 317.98 133609 381.57
M18
0.10 51457 124.03 64322 155.03 77186 186.04 102914 248.06 144723 348.83 173668 418.59
0.14 47752 155.02 59690 193.78 71628 232.53 95503 310.05 134302 436.00 161162 523.20
M18
0.10 55415 130.17 69269 162.72 83123 195.26 110830 260.35 155855 366.12 187026 439.34
0.14 51578 164.67 64472 205.84 77366 247.01 103155 329.35 145062 463.15 174075 555.77
M20
0.10 65534 173.72 81918 217.16 98301 260.59 131068 347.45 184315 488.60 221178 586.32
0.14 60886 218.17 76108 272.71 91329 327.26 121772 436.34 171243 613.61 205491 736.33
M20
0.10 70115 181.58 87643 226.97 105172 272.36 140229 363.15 197198 51.68 236637 612.82
0.14 65319 230.55 81649 288.19 97979 345.82 130638 461.10 183710 648.42 220452 778.10
