| Maintenance Dieci s.r.l. 122 / 199 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]
Coefficient of
friction
4.8 5.8 6.8 8.8 10.9 12.9
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
Preload
(N)
Tightening
torque:
(Nm)
M22
0.10 81221 236.88 101526 296.10 121831 355.32 162442 473.76 228433 666.23 274120 799.48
0.14 75534 298.75 94417 373.43 113301 448.12 151068 597.49 212439 840.22 254927 1008.27
M22
0.10 86164 246.02 107705 307.53 129246 369.04 172329 492.05 242337 691.94 290804 830.33
0.14 80332 313.41 100415 391.76 120498 470.11 160664 626.82 225933 881.46 271120 1057.75
M24
0.10 98516 308.56 123145 385.70 147773 462.84 197031 617.12 277075 867.83 332490 1041.40
0.14 91693 390.33 114617 487.92 137540 585.50 183387 780.67 257887 1097.82 309465 1317.38
M24
0.10 104079 319.62 130099 399.52 156119 479.43 208152 639.23 292723 898.92 351268 1878.71
0.14 97096 408.12 121370 510.15 145644 612.18 194192 816.24 273083 1147.84 327699 1377.41
M27
0.10 127922 448.43 159903 560.54 191884 627.65 255845 896.87 359782 1261.22 431738 1513.46
0.14 119185 569.67 148981 712.09 178778 854.51 238370 1139.34 335208 1602.20 402250 1922.64
M30
0.10 16818 623.80 201022 779.75 241226 935.70 321635 1247.60 452299 1754.43 542759 2105.32
0.14 149957 795.14 187446 993.93 224936 1192.72 299914 1590.29 421754 2236.34 506105 2683.61
