10
MAINTENANCE
120 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]
10.19 - Hydraulic fittings tightening torques
Inserts with 60° nose - BSP thread
Thread 1/18.28 1/4.19 3/8-19 1/2-14 5/8-14 3/4-14 1“-11 1“1/4-11 121/2-11
(N·m) 12-14 14-16 25-28 45-60 55-70 90-110 120-140 170-190 200-245
Inserts with 60° nose - METRIC thread
Thread 10x1 12x1.5 14x1.5 16x1.5 18x1.5 22x1.5 26x1.5 28x1.5 30x1.5
(N·m) 12-14 13-15 15-18 25-28 27-30 50-60 60-75 80-100 110-130
SERIES DIN RANGE „L“
Thread 12x1.5 14x1.5 16x1.5 18x1.5 22x1.5 26x1.5 30.2 36x1.5 45x1.5 52x1.5
(N·m) 13-15 15-18 25-28 27-30 50-60 30-75 85-105 120-140 170-190 190-230
SERIES DIN RANGE „S“
Thread 14x1.5 16x1.5 18x1.5 20x1.5 22x1.5 24x1.5 30x2 36x2 42x2 52x2
(N·m) 15-18 25-28 27-30 43-54 50-62 60-75 90-110 125-145 170-190 200-245
