COMPONENTS DESCRIPTION
72 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]
Before starting the vehicle, carefully examine the
straps, buckles and fastening devices to the structure.
If some component is damaged or worn, replace the
seat belt or the component before operating the
vehicle.
Remain seated with the seat belts fastened properly
for all the time of operation of the vehicle to reduce
the risk of injury in case of accident.
Following an accident of a certain importance, replace
the seat belts, even if they do not appear damaged.
To fasten the seat belt is necessary to:
Figure: 150416-1
• Insert the latch plate “1” in the buckle “2”.
Figure: 150416-2
• Make sure of that the hooking occurred, and then
adjust the belt around the body.
• The belt is considered properly connected when
it is close to the body.
To remove the belt it is necessary to:
Figure: 150416-3
• Press the red button “1” on the buckle “2”.
• Then remove the latch plate “3”.
WARNING
Drive the vehicle only with safety belt
properly worn, fastened and adjusted.
Operating without the seat belt fastened
increases the risk of accidents.
Do not use damaged or worn seat belts. If worn,
damaged or yielded belts are used, they can
break or yield in case of collision resulting in
serious injury to the operator.
7.1.14 - Emergency stop
Figure: 150420-1
In emergency conditions, the machine can be stopped
using the Emergency stop button in the cab (fig.
150420-1); the stop occurs immediately.
