EQUIPMENT

94 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]

NOTE

The vehicle is supplied with the equipment useful for the vehicle use and maintenance.

Tool bag

The tool carrier bag is made up of:

Socket wrench

Set of wrenches

Screwdriver

Lubricator

Adaptor cable for engine diagnostics

(Only FPT engines)

Protruding load signal (only Italy)

Rotating light
