VEHICLE DESCRIPTION 5
AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A] 47
NOTE
The images used to describe components and controls refer to a complete vehicle with all
accessories; these may vary depending on the attachments and on the configuration chosen.
Refer to the “Definitions” manual to understand references such as: Right side, Left side, Front and Back used
in the manual.
150641-1: Front view
150641-2: Rear view
150641-3: Left view
150641-4: Right view
