TECHNICAL DATA
138 AXH1157-UK (ENG) L3500 L4700 F7000 [FPT S3A]
MAF3523 MAF3524
Parking braking Acting on the rear axle Acting on the rear axle
Front axle Swinging, self-locking Swinging, self-locking
Type of steering 4 wheels / transversal / 2 wheels 4 wheels / transversal / 2 wheels
Engine oil quantity 10,00 L (2,64 gal) 10,00 L (2,64 gal)
Engine oil specifications DIECI ENGINE HP SAE 15W-40; (<
-20°C / < -4°F) DIECI ENGINE
EVOLUTION TIR4 SAE 10W-30
DIECI ENGINE HP SAE 15W-40; (<
-20°C / < -4°F) DIECI ENGINE
EVOLUTION TIR4 SAE 10W-30
Front axle oil quantity 7,50 L (1,98 gal) 7,50 L (1,98 gal)
Front reduction gears oil quantity 1,25 L (0,33 gal) 1,25 L (0,33 gal)
Front axle oil specifications DIECI GEAR EP/E LS 85W-90 API GL-5,
MIL-L-2105D; (< -20°C / < -4°F) DIECI
SPECIAL LS SYNT AXEL OIL 75W-90
DIECI GEAR EP/E LS 85W-90 API GL-5,
MIL-L-2105D; (< -20°C / < -4°F) DIECI
SPECIAL LS SYNT AXEL OIL 75W-90
Rear axle oil quantity 7,50 L (1,98 gal) 7,50 L (1,98 gal)
Rear reduction gears oil quantity 1,25 L (0,33 gal) 1,25 L (0,33 gal)
Rear axle oil specifications DIECI GEAR EP/E LS 85W-90 API GL-5,
MIL-L-2105D; (< -20°C / < -4°F) DIECI
SPECIAL LS SYNT AXEL OIL 75W-90
DIECI GEAR EP/E LS 85W-90 API GL-5,
MIL-L-2105D; (< -20°C / < -4°F) DIECI
SPECIAL LS SYNT AXEL OIL 75W-90
Transmission gearbox oil quantity 1,50 L (0,4 gal) 1,50 L (0,4 gal)
Transmission gearbox oil
specifications
(from -10°C/14°F to +35°C/95°F) DIECI
UTTO FLUID WB SAE 10W/30; (from
-30°C/-22°F to +10°C/14°F) DIECI MTF
III FLUID
(from -10°C/14°F to +35°C/95°F) DIECI
UTTO FLUID WB SAE 10W/30; (from
-30°C/-22°F to +10°C/14°F) DIECI MTF
III FLUID
Braking circuit oil quantity 1,20 L (0,32 gal) 1,20 L (0,32 gal)
Braking circuit oil specifications DEXRON II DEXRON II
Coolant quantity 7,00 L (1,85 gal) 7,00 L (1,85 gal)
Coolant specifications Antifreeze Red Antifreeze Red
Grease quantity 4,00 kg (9 lb) 4,00 kg (9 lb)
Grease specifications NLGI - 1 NLGI - 1
Hydraulic system (total) 145,0 L (38,3 gal) 145,0 L (38,3 gal)
Hydraulic oil type DIECI Hydro Telehandler Fluid ISO46 DIECI Hydro Telehandler Fluid ISO46
Air conditioning refrigerant quantity 1,10 kg (2 lb) 1,10 kg (2 lb)
Air conditioning refrigerant
specifications
R134A R134A
Fuel tank 90,0 L (23,78 gal) 90,0 L (23,78 gal)
Acoustic pressure: Reference standard
for stopped and running vehicle
- -
Acoustic pressure: Value with stopped
vehicle
- -
Acoustic pressure: Value with running
vehicle
- -
Acoustic pressure: Reference standard
perceived by the operator
- -
Acoustic pressure: Value perceived by
the operator with open cab
- -
Acoustic pressure: Value perceived by
the operator with closed cab
- -
Acoustic power: Reference standard - -
