SM720 Service Manual Edition 5
66
101
101
Cover AD (H-PRTCOVER)
44013502800403
Cover AB (H-SIDE)
44013502800200 – (Gray)
44013502801100 – (Blue)
Catch to
Binding Head
102
102
102
102
102
102
Front View
Rear View
BKT AD (SM500H Rear)
44013501800404
102
102
102
101
4
5
6
7
Screw Type:
101 – SEMS B M3x6
102 – SEMS B M4x6
