SM720 Service Manual Edition 5
67
Bracket AP (Printer Base)
44013501801600
101
101
1
03
103
Bracket AM (Wire/Supp)
44013301801300
Insulator AD (I/F Bottom)
44011604800400
TWB-01750-0 (SM500V2 ETH/RS485)
22TWB100017500
101
101
101
101
101
101
ELEC BLK (SM300 A/D-1)
44012490910400
Bracket AK (Load Support)
44013501801101
Bracket AM (Wire/Supp)
44013301801300
101
101
101
101
SM500 1MB ETHT M/B KIT
0EX00401160002
8
9
10
11
Screw Type:
101 – SEMS B M3x6
102 – SEMS B M4x8
103 – SEMS B M3x8
102
102
102
101
101
