Digi SM-720 - Page 70

SM720 Service Manual Edition 5
68
101
101
102
102
103
103
Joint AA (671)
44013004900101
Spring AA
44010408300100
Joint AA
41012404900103
A
xis AA (DS671H)
41012401300103
104
104
104
104
104
104
104
104
Bracket AN (Base plate)
440135018014X
X
101
101
106
106
106
106
WELASSY AA (Hook Top)
44013050200102
Bracket BP (Hook Support)
44013501804200
105
105
105
104
104
ELEC BLK (SM500H CLCD PWR, EC)
44011690904900
BKT BD (SM500H Power)
44013501803000
12
13
14
15
Screw Type:
101 – Allen Cap M6x12
102 – Hex Nut T3M6
103 – Plain Washer M10
104 – SEMS B M3x8
105 – SEMS B M4x8
106 – SEMS B M4x6
