Digi SM-720 Service Manual

SM720 Service Manual Edition 5
69
102
102
102
102
102
102
Bracket AE (Frame Top)
44013501800502
Bracket AM (Col Main)
44013501801301
Bracket AG (Frame PRT Wall)
44013501800701
Bracket BG (LCD Cover)
44013501803300
Bracket AE (Frame Top)
44013501800502
Bracket AH (AC Switch)
440135018008xx
A
C Inlet
102
102
101
101
101
101
101
Bracket AF (Load Center)
44013501800601
Bracket AK (Load Support)
44013501801101
LOADCELL Blk AB (15 KG)
44012460200200
101
101
101
101
105
10
5
105
105
Bracket AM (Top Support)
44013001801302
16
17
18
19
Screw Type:
101 – SEMS B M4x10
102 – SEMS B M3x6
103 – SEMS B M4x8
104 – SEMS B M3x8
105 – FLANGE NUT M4
103
103
103
104
104
