1.3 Dual Display Solution: HDMI/VGA/DVI-I Connection
DS-4200 Pro Series, DS-4200-RM Pro Series, DS-8200-RM Pro Series, DS-4200 Pro+
Series, DS-4200-RM Pro+ Series, DS-8200-RM Pro+ Series, DS-4300 Pro+ Series,
DS-4300-RM Pro+ Series and DS-8300-RM Pro+ Series provide HDMI and VGA port
for local display. Users can connect both of HDMI and VGA at the same time for
video output.
DS-1100 Pro Series, DS-2100 Pro Series, DS-1100 Pro+ Series and DS-2100 Pro+
Series provide HDMI and DVI-I port for local display. Users can connect both of HDMI
and DVI-I at the same time for video output.
Scenario A: If both monitors are Full HD(1920x1080),those will be shown as Full HD.
Scenario B: If both monitors are VGA (1024x768), those will be shown all as VGA.
Scenario C: If one of monitors is 1920x1080 and another is 1024x768, both monitors
are set as 1024x768
