C
HAPTER
5
| Interface Configuration
Port Configuration
– 147 –
u Autonegotiation (Port Capabilities) – Allows auto-negotiation to be
enabled/disabled. When auto-negotiation is enabled, you need to
specify the capabilities to be advertised. When auto-negotiation is
disabled, you can force the settings for speed, mode, and flow
control.The following capabilities are supported.
n
10h - Supports 10 Mbps half-duplex operation.
n
10f - Supports 10 Mbps full-duplex operation.
n
100h - Supports 100 Mbps half-duplex operation.
n
100f - Supports 100 Mbps full-duplex operation.
n
1000h - Not supported.
n
1000f (Gigabit ports only) - Supports 1000 Mbps full-duplex
operation.
n
10Gh - Not supported.
n
10Gf (10 Gigabit ports only) - Supports 10 Gbps full-duplex
operation.
n
Sym (Gigabit only) - Check this item to transmit and receive pause
frames.
n
FC - Flow control can eliminate frame loss by “blocking” traffic from
end stations or segments connected directly to the switch when its
buffers fill. When enabled, back pressure is used for half-duplex
operation and IEEE 802.3-2005 (formally IEEE 802.3x) for full-
duplex operation.
Default: Autonegotiation enabled on Gigabit and 10 Gigabit ports;
Advertised capabilities for
100BASE-FX (SFP
2
/ SFP+) – 100full
1000BASE-T – 10half, 10full, 100half, 100full, 1000full
1000BASE-SX/LX/ZX (SFP
2
/ SFP+) – 1000full
10GBASE-SR/LR/ER (SFP+) – 10Gfull
u Speed/Duplex – Allows you to manually set the port speed and
duplex mode. (i.e., with auto-negotiation disabled)
u Flow Control – Allows automatic or manual selection of flow control.
WEB INTERFACE
To configure port connection parameters:
1. Click Interface, Port, General.
2. Select Configure by Port List from the Action List.
3. Modify the required interface settings.
2. 100BASE-FX SFP port is only applicable for DG-GS4528FSE
