Positioning the image Digital Projection Ltd. E-Vision Laser 13000 WU Series
Combined shift is reduced
Full horizontal or vertical shift
See Lens control on
page42 for more
information on shifting the
lens.
Any single adjustment outside the
ranges specified on the following
page may result in an unacceptable
level of distortion, particularly at the
corners of the image, due to the
image passing through the
periphery of the lens optics.
If the lens is to be shifted in two
directions combined, the maximum
range without distortion will be
somewhat less, as can be seen in
the illustrations.
Reference Guide
Rev A June 2019
page 103
Notes
