Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series
3D menu
3D
3D Format Auto
DLP Link Off
Eye Swap Normal
Dark Time 1.95 ms
3D Sync
Offset 100
Reference Internal
If 3D Format is set to Off,
all other 3D settings will
be unavailable.
See 3D connections on
page28 for more
information about
supported 3D formats.
The following settings are
not available when 3D is
on:
Image > Brightness,
Contrast, Saturation, Hue,
Sharpness, Noise
Reduction, Freeze,
Resync.
Color > Color Space.
Geometry > Aspect Ratio,
Digital Zoom, Overscan.
Setup > Screen Setting,
Auto Source, Trigger-1,
Trigger-2.
PIP > all settings.
Also: See 3D types on the
next page and See Some
3D settings explained on
page73
See 3D formats on
page109 for 3D
resolutions and frame
rates.
Use this menu to enable, disable and set up 3D input, as follows:
l 3D Format — Off, Dual Pipe and Frame Sequential.
Frame Sequential is for sources where Left and Right eye images are delivered as alternate frames from
a single input. Dual Pipe is for sources where Left and Right eye are delivered on separate inputs.
l DLP Link — Off / On.
DLP Link On emits a sync pulse for the 3D glasses via the projected image. DLP Link Off will send the
sync pulse to the sync out connector to use with an external third party emitter.
l Eye Swap — Normal and Reverse.
(set to Reverse if the left- and right-eye images are displayed in the wrong order)
l Dark Time — 0.65 ms, 1.3 ms and 1.95 ms.
Set to reduce the effect of banding and image overlapping when viewed through 3D glasses.
3D Sync
l Offset.
Use the LEFT and RIGHT arrow buttons to compensate for image overlapping (ghosting) when viewed
through 3D glasses.
l Reference— External and Internal.
Select the source of the 3D sync. Internal is referenced to the incoming video. External is for Frame
Sequential 3D sources and is supplied by the graphics card or player.
Operating Guide
Rev A June 2019
page 71
