Appendix A: supported signal input modes Digital Projection Ltd. E-Vision Laser 13000 WU Series
SDI formats
Timing SDI Link Mode Signal Standards Color Encode Sampling Structure Bit Depth
NTSC SD SMPTE 259M-C 270Mbps SD YCbCr 4:2:2 10
PAL SD SMPTE 259M-C 270Mbps SD YCbCr 4:2:2 10
1035i60 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080i59 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080i60 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080P30 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080P25 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080i50 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080P24 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
720P60 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
720P50 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080Sf25 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080Sf30 HD SMPTE 292M 1.5Gbps HD YCbCr 4:2:2 10
1080P50 3G Level A SMPTE 424M 3Gbps YCbCr 4:2:2 10
1080P59 3G Level A SMPTE 424M 3Gbps YCbCr 4:2:2 10
1080P60 3G Level A SMPTE 424M 3Gbps YCbCr 4:2:2 10
1080P50 3G Level B SMPTE 424M 3Gbps YCbCr 4:2:2 10
1080P59 3G Level B SMPTE 424M 3Gbps YCbCr 4:2:2 10
1080P60 3G Level B SMPTE 424M 3Gbps YCbCr 4:2:2 10
Reference Guide
Rev A June 2019
page 111
