Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series
Position and phase
Some of the settings
within the Position and
Phase sub-menu, Phase,
Tracking and Sync Level,
affect only VGA input
source. These settings are
not available if the
projector is using a
different source.
Adjust the Phase after
adjusting Tracking.
Position and Phase
V Position 100
H Position 100
Phase 100
Tracking 100
Sync Level 100
l V Position and H Position
Set the sliders as required.
l Phase
Adjusts the phase of the pixel sampling clock relative to the incoming signal. Adjust the phase if noise is
visible.
l Tracking
Adjusts the frequency of the pixel sampling clock. Flicker or vertical banding indicate poor tracking.
l Sync Level
Adjusts the voltage level of the signal detection circuitry. Adjust if the projector loses sync during scenes
where the signal drops below black.
Highlight the setting you wish to edit, and then press ENTER/OK, or the LEFT or RIGHT arrow button to
open the slider.
Use the LEFT and RIGHT arrow buttons to adjust the slider.
Press EXIT to close the slider and return to the menu, or MENU to exit both the slider and the menu.
Operating Guide
Rev A June 2019
page 45
