Appendix A: supported signal input modes Digital Projection Ltd. E-Vision Laser 13000 WU Series
3D formats
*1: HB(High Bandwidth)
mode without
warping/blending.
*2: 8-bit / color.
*3: Frame drop at scaler
and frame doubling at
formatter. Sources greater
than 60 fps are processed
at half the frame rate, then
frame doubled.
*4 Output display frame
rate up to 96Hz for 24Hz
3D input
Standard Resolution
V-Freq
(Hz)
V-
Total
H Freq.
(kHz)
HDMI
1/2
DisplayPort /
DVI-D
HB Dual-pipe
HDMI
(*1)
HB
DisplayPort
(*1)
Output Frame
Rate (Hz)
Remarks
720p50 Frame Packing 1280x720 50.00 1470 37.50
ü
100 *3
720p59 Frame Packing 1280x720 59.94 1470 44.96
ü
120 *3
720p60 Frame Packing 1280x720 60.00 1470 45.00
ü
120 *3
720p50
Top-and-
Bottom
1280x720 50.00 750 37.50
ü ü
100 *3
720p59
Top-and-
Bottom
1280x720 59.94 750 44.96
ü ü
120 *3
720p60
Top-and-
Bottom
1280x720 60.00 750 45.00
ü ü
120 *3
1080p23 Frame Packing 1920x1080 23.98 2205 26.97
ü
96 *4
1080p24 Frame Packing 1920x1080 24.00 2205 27.00
ü
96 *4
1080i50
Side-by-Side
(Half)
1920x1080 50.00 1125 56.25
ü ü
100 *3
1080i59
Side-by-Side
(Half)
1920x1080 59.94 1125 67.43
ü ü
120 *3
1080i60
Side-by-Side
(Half)
1920x1080 60.00 1125 67.50
ü ü
120 *3
1080p50
Side-by-Side
(Half)
1920x1080 50.00 1125 56.25
ü ü
100 *3
1080p59
Side-by-Side
(Half)
1920x1080 59.94 1125 67.43
ü ü
120 *3
1080p60
Side-by-Side
(Half)
1920x1080 60.00 1125 67.50
ü ü
120 *3
1080p50
Top-and-
Bottom
1920x1080 50.00 1125 56.25
ü ü
100 *3
1080p59
Top-and-
Bottom
1920x1080 59.94 1125 67.43
ü ü
120 *3
1080p60 Top-and-
Bottom
Top-and-
Bottom
1920x1080 60.00 1125 67.50
ü ü
120 *3
1080p50
Frame
Sequential
1920x1080 50.00 1125 56.25
ü ü
100 *3
1080p59
Frame
Sequential
1920x1080 59.94 1125 67.43
ü ü
120 *3
1080p60
Frame
Sequential
1920x1080 60.00 1125 67.50
ü ü
120 *3
