Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series
Edge blend menu
Edge Blend
Edge Blend On
Align Pattern Off
Blend Start ►
Blend Width ►
Black Level Uplift ►
Reset
When Edge Blend is set to
Off, all other edge blend
settings are disabled.
The picture in the blend
region needs to be
delivered to all
overlapping projectors,
which may require a
special setup of the
source.
Use this menu to blend together images from an array of two or more projectors. The feature feathers the light
output of the projector within the edges that overlap with other projectors in the array: as a result, the
overlapping edges are evenly lit and easily blend in with the rest of the image.
l Edge Blend
Enable and disable Edge Blend
l Align Pattern
Add markers to the image showing the edges of the blend area and making the overlaps more visible to
help adjust the physical position of the projectors in the array.
l Blend Start
Determine the start point of the blended regions. top, bottom, left right
l Blend Width
Determine the width of the blended regions.
l Black Level Uplift
Adjust black levels to compensate if the blended regions appear brighter than the rest of the image.
l Reset
Reset all Edge Blend settings to their factory default values.
Operating Guide
Rev A June 2019
page 67
