Control connections Digital Projection Ltd. E-Vision Laser 13000 WU Series
RS232 connection example
The Protocol Guide is
available separately
All of the projector’s features can be controlled via a serial connection, using commands described in the Protocol Guide.
Straight through cable
Computer to Projector
Connection Guide
Rev A June 2019
page 33
Notes
