Digital Projection E-Vision Laser 13000 WU Series - Roll and Pitch

Digital Projection Ltd. E-Vision Laser 13000 WU Series Positioning the screen and projector
Roll and pitch
The projector can be operated in numerous positions.
360˚
2
Pitch
30˚
330˚
2
1
Roll
In portrait mode, it is
recommended to position the
projector with inputs facing
upward, as shown in the diagram.
1. Recommended positions:
inputs side up
2. Also possible.
