Digital Projection E-Vision Laser 13000 WU Series User Manual

Digital Projection Ltd. E-Vision Laser 13000 WU Series Using the projector
Image menu
Picture Mode High Bright
Brightness 100
Contrast 100
Saturation 100
Hue 100
Sharpness 10
Noise Reduction ►
Gamma 2.2
Dynamic Black Off
Light Off Timer – – – –
Position and Phase ►
▼
▲
Freeze
Resync
l Picture Mode
Choose from High Bright, Presentation and Video.
Use a different setting depending the type of input source.
Press ENTER/SELECT to open the list.
Use the UP and DOWN arrow buttons to select a picture mode from the list, then press ENTER/OK to
confirm your choice.
Press EXIT to return to the main menu.
l Brightness, Contrast, Saturation, Hue, Sharpness
Highlight the setting you wish to edit, and then press ENTER/OK, or the LEFT or RIGHT arrow button to
open the slider.
Use the LEFT and RIGHT arrow buttons to adjust the slider.
Press EXIT to close the slider and return to the menu, or MENU to close the slider and return to the
projected image.
l Noise Reduction
Choose a level of noise reduction from Off, Low, Middle and High.
l Gamma
Choose a de-gamma curve from 1.0, 1.8, 2.0, 2.2, 2.35, 2.5, S-Curve, and DICOM.
Used correctly, the Gamma setting can improve contrast while maintaining good details for blacks and
whites.
If excess ambient light washes out the image and it is difficult to see details in dark areas, lower the
Gamma setting to compensate. This improves contrast while maintaining good details for blacks.
Conversely, if the image is washed out and unnatural, with excessive detail in black areas, increase the
setting.
S-Curve is an enhanced mid-tone gamma.
DICOM is a simulated DICOM display, which can be used for training applications.
l Dynamic Black
Set to On to allow for increased contrast in darker scenes by modulating the light source.
l Light Off Timer
When Dynamic Black is On, the Light Off Timer will define if laser light source will turn off after a period
of time has passed. The options are: Disable, 0.5, 1.0, 1.5, 2.0, 3.0, 4.0 seconds.
l Position and Phase
Open the sub menu to adjust the position and phase settings.
l Freeze
Freezes the current frame.
l Resync
Press ENTER/OK to force the projector to resynchronise with the current input
Rev A June 2019
page 44
Operating Guide
Notes
