Digital Projection E-Vision Laser 13000 WU Series - Rotation Example

Using the projector Digital Projection Ltd. E-Vision Laser 13000 WU Series
Rotation example
1
2
3
1. DMD™ area
The DMD™ is not rotated. It still covers the area that would be occupied by the image
without correction.
2. Rotated image
The image is smaller than the surrounding DMD™ area. It is scaled in order to remain within
the DMD™ area.
3. Angle of rotation
Each step on the slider is 0.25° of rotation. In this example the angle is 5°, therefore Rotation
value is 20.
Operating Guide
Rev A June 2019
page 63
