Digital Projection Ltd. E-Vision Laser 13000 WU Series Positioning the image
Positioning the image
See Lens control on
page42 for more
information on shifting the
lens.
Whenever possible,
position the projector so
that the lens is centered
for the highest quality
Shifting the lens up (rising front)
Centred Lens
Shifting the lens down (falling front)
The normal position for the projector is at the centre of the
screen. However, you can set the projector above or below the
centre, or to one side, and adjust the image using the Lens
shift feature (known as rising and falling front) to maintain a
geometrically correct image.
Rev A June 2019
page 102
Reference Guide
Notes
