Digital Projection Ltd. E-Vision Laser 13000 WU Series Appendix B:wiringdetails

3G-SDI in, 3G-SDI out

3G-SDI connector

75 ohm BNC

HDBaseT input

HDBaseT / LAN

RJ45 socket.

Rev A June 2019

page 114

Reference Guide
