Ventilation
Instructions for Use Apollo SW 4.5n 139
Part Number: 9053586, 3rd edition
Starting the pressure-controlled ventilation mode
Table 6. Adjustment ranges and factory settings for
Pressure Mode
1. When all the parameters have been preset,
press the rotary knob to start pressure ventilation
(4 in Figure 73).
The parameter buttons turn dark green and
display the preset parameter values. The
“Pressure” indication in the status field stops
flashing and is displayed continuously. Pressure
ventilation begins.
If a pressure parameter has to be changed
during ventilation:
– Press the button for the parameter to be
changed, turn the rotary knob to the desired
value, and press the rotary knob to confirm.
Note: Pressure Mode can also be started without
presetting values:
– Press the >Press Mode< key located at
the bottom of the display panel, and press
the rotary knob. Default parameter values
are used.
Note: There is 15-second timeout period for
making ventilation mode changes, with a
5-second audible tone sequence after the
first 10 seconds. If the new setting is not
confirmed within the timeout period, the
current ventilation setting remains in effect.
Ventilation
parameters
Adjustment
range
Factory
setting
1)
1) Site defaults can be configured instead.
Pressure limitation
>PINSP<
[cmH
2O]
5 to 70
min. PEEP
+5
15
Frequency
>Freq<
2),3)
[bpm]
2) Depending on the configuration, the inspiratory time (TINSP) can be
automatically changed together with adjustment of the frequency so that the
resultant ratio of inspiration to expiration (I : E) remains constant. Only
applies if trigger = OFF. See the chapter “Configuration”.
3 to 100 12
Inspiratory time
>T
INSP<
3)
[sec.]
3) The resultant ratio of inspiration to expiration (I : E) is also displayed in
parallel.
0.2 to 6.7 1.7
>PEEP<
4)
[cmH2O]
4) Depending on the configuration, the pressure limit (PINSP) can be changed
automatically together with adjustment of the PEEP value.
See the chapter “Configuration”.
0 to 20
max. P
INSP –5
0
Trigger sensitivity
>Trigger<
[L/min]
OFF,
0.3 to 15
3.0
(Press. Supp.)
OFF
(Vol./Press.
Mode)
Pressure Support
>ΔP
PS<
5)
[cmH2O]
5) Optional.
OFF,
3 to 50 5
(Press. Supp.)
max. P
MAX–PEEP OFF
(Vol./Press.
Mode)
Rise time
>TSLOPE<
[sec.]
0.0 to 2.0 0.0
Age
>Age<
[years]
<1 to 120 40
Ideal body weight
>Weight<
5)
[kg/lbs.]
1 kg to 120 kg,
1 lbs. to 240 lbs.
--
