Dräger Apollo User Manual

System Components
Instructions for Use Apollo SW 4.5n 39
Part Number: 9053586, 3rd edition
Writing table
Figure 7. Writing TableThe Apollo is equipped with a writing table
(1 in Figure 7) which can be moved left or right or
folded down completely for convenient positioning.
To fold down the writing table, support the table with
one hand, then pull up on the release knob
(2 in Figure 7) and fold down. To bring the table up
again, swing it upward until it clicks into place.
Gas flow diagram
1
2

Dräger Apollo Specifications

General

Type	Anesthesia Workstation
Gas Supply	O2, N2O, Air
Integrated Monitoring	Yes
Ventilation Modes	Volume Control, Pressure Control, SIMV, Pressure Support, Manual
Vaporizer	Dräger Vapor 2000
Patient Monitoring	ECG, SpO2, NIBP, Temperature
Power Supply	100 – 240 VAC, 50/60 Hz
Tidal Volume Range	20-1500 ml
Vaporizer Mounts	Up to 2
