Configuration
204 Instructions for Use Apollo SW 4.5n
Part Number: 9053586, 3rd edition
Pulse volume (for SpO2, optional)
See 3 in Figure 125.
0 = off
to
9 = maximum volume
Factory setting: 3
Date/Time/Language
See 4 in Figure 125.
Date/Time
– day, month, year
– hh:mm
Time format
– 12 hrs.
– 24 hrs.
Factory setting: 12 hrs.
Language
Selects the language of the display text.
– English (US)
Factory setting: English (US)
Parameters
Figure 126. Parameters Standby Configuration ScreenThe following settings can be selected in the
Parameters standby configuration screen
(refer to Figure 126):
Scaling
See 1 in Figure 126.
– The setting is made automatically or by selecting
a pre-set scale.
MPa
Waveform parameters Factory setting
CO
2:
50, 100 mmHg, auto
auto
P
AW:
25, 50, 75 hPa, auto
auto
Flow:
15, 30, 60, 120 L per minute
auto
Tidal volume:
50, 150, 500, 1000 mL, auto
auto
O
2: 100 %, auto auto
