Dräger Apollo User Manual

Troubleshooting
274 Instructions for Use Apollo SW 4.5n
Part Number: 9053586, 3rd edition
Warning
(31)
INSP. O2 LOW Inspiratory O2 concentration is below the
low alarm limit.
Check O2 concentration and fresh-gas
setting.
Check O
2 supply.
Check breathing system and breathing
bag for large leaks.
Warning/
Advisory
(29/10)
INTERNAL TEMP. HIGH* Temperature inside the device is too high. Check ambient conditions.
Ensure air circulation at back of device.
Fan is defective. Call DrägerService.
Extreme, non-physiological ventilation
settings.
Check ventilation settings.
Caution/
–
(14/–)
LOSS OF CONFIG DATA* Loss of settings and/or configuration data. Check the current settings and default
settings.
Repeat settings if necessary.
Call DrägerService.
Alarm can be reset by pressing > <.
Caution/
Advisory
(14/7)
MAC LOW?* The expiratory MAC value has fallen
below the lower alarm limit of the
automatic agent alarm.
Check patient condition.
Confirm alarm, if case is closed.
Check vaporizer fill level.
Check correct position of vaporizer.
Check for leaks in breathing system and
breathing bag.
Caution
(13)
MINUTE VOL. HIGH Upper alarm limit for the minute volume
has been exceeded.
Correct the tidal volume or breathing
rate.
Check spontaneous breathing.
Correct the trigger level if necessary
when using Pressure Support mode.
Caution
(22)
MINUTE VOL. LOW Lower alarm limit for the minute volume
has been fallen short of.
Check breathing system.
Check ventilation settings.
Correct the trigger level if necessary
when using Pressure Support mode.
Check the patient's trigger capability.
Tube sealed/kinked. Check tube.
Leak. Check tube, hoses, filters, bellows,
absorber.
Reduced tidal volume due to pressure
limitation.
Correct ventilation settings.
Insufficient fresh-gas flow. Increase fresh-gas flow.
Advisory/
–
(8/–)
N
2O CYLIND. CONNECT.?* Pressure sensor for backup cylinder not
connected.
Check pressure sensor connection.
Warning/
Advisory
(25/7)
N
2O CYLIND. EMPTY* N2O backup cylinder empty or closed and
central N
2O supply not available or not
connected.
Use a new N
2O backup cylinder or open
the cylinder valve.
Use the pipeline supply.
Priority Message Cause Remedy
