Dräger Apollo User Manual

Troubleshooting
276 Instructions for Use Apollo SW 4.5n
Part Number: 9053586, 3rd edition
Warning
(31)
NO O2 SUPPLY O2 supply has failed. Open O2 backup cylinder.
Check central supply.
Pipeline supply hose not connected or
kinked.
Check connection to pipeline supply.
O
2 cylinder empty or closed. Connect a full O2 cylinder or open the
cylinder valve.
Warning
(31)
NO SPO
2 PULSE No pulse signal detected with the SpO2
measurement for approx. 10 seconds.
Check patient's condition!
Check application of the SpO
2 sensor.
NiBP measurement on the same arm. Measure blood pressure on other arm.
Advisory/
–
(8/–)
O
2 CYLIND. CONNECT.?* Pressure sensor of backup cylinder not
connected.
Check pressure sensor connection.
Warning/
Advisory
(28/7)
O
2 CYLIND. EMPTY* O2 backup cylinder empty or closed and
pipeline O2 supply not available or not
connected.
Use a new O2 backup cylinder or open
the cylinder valve.
Use the pipeline supply.
Advisory
(10)
O
2 CYLIND. LOW Pressure has dropped below the
pressure limit set for the O
2 cylinder.
Use a new O
2 backup cylinder.
Use the pipeline supply.
Caution
(11)
O
2 FLOW MEAS. FAIL Fresh-gas flow measurement for O2 has
failed.
Use only oxygen as fresh gas and
observe total flow meter.
Check fresh-gas flow settings using total
flow meter and set a fresh-gas flow
greater than or equal to measured or set
minute volume.
Call DrägerService.
Caution
(11)
O
2 PIPELINE FAIL O2 supply has failed. Open O2 backup cylinder.
Check pipeline supply.
Pipeline supply hose not connected or
kinked.
Check connection to pipeline supply.
O
2 cylinder empty or closed. Connect a full O2 cylinder or open the
cylinder valve.
Caution
(11)
O
2 SENSOR FAIL* O2 sensor is defective. Ensure adequate substitute monitoring.
Call DrägerService.
Caution
(14)
PEEP HIGH Exp. pressure 5 cmH
2O above PEEP for
2 breaths, or
Exp. pressure 5 cmH
2O above PEEP in
Pressure Support mode for more than
30 seconds.
In automatic ventilation modes: Check
the ventilation parameters,
Check the anesthetic gas scavenging
line.
Caution
(12)
PINSP NOT ACHIEVED The inspiratory pressure set in Pressure
Mode is not achieved.
Check set ventilation parameters; repair
leak if applicable.
Fresh-gas shortage. Check fresh-gas setting.
Priority Message Cause Remedy
