When “MASTER SETTING ERROR” is Displayed
s
When “MASTER SETTING ERROR” is Displayed
The message “ MASTER SETTING ERROR ” is displayed on the LCD panel.
Follow the steps below to remove the master jammed in the feed section, and try platemaking again.
s
How to remove the master
Troubleshooting
6.
1
Press the “scanner switch” to slide the scanner
unit.
2
Remove the “master” jammed in the feed
section.
Remove the master
440212c
440217
Slide the “scanner unit” to return it to its
original position.
4
Make another plate.
5
3
Open and close the “master cover”.
(
Press the “master cover release lever”. )
Master cover
Master cover release lever
440e211
scanner
switch
