When “
SET MASTER ROLL PROPERLY
” is Displayed
s
When “SET MASTER ROLL PROPERLY” is Displayed
The message
“
SET MASTER ROLL PROPERLY
”
is displayed on the LCD panel.
Follow the steps below to set the master again.
"
Only use a master roll designed for use in this machine.
IMPORTANT
:
s
How to Set the Master Roll
440212b
440215
Master
1
Press the “scanner switch” to slide the scanner
unit.
2
Press the “master cover release lever”.
(Marked PUSH.) The master cover will open up.
Master cover release lever
"
Do not touch the heat generator of thermal
head. Doing so may cause damages,
leading to a malfunction of plate making.
“
Heat generator of thermal head
”
a
see p.100
IMPORTANT
:
Master cover
3
Pull out the “master”, insert it under the “bar”,
and align its leading edge with the “set line”.
Set line
Bar
440e211
scanner
switch
