Duplo DUPRINTER DP-460e - Document;Printing Paper Specification; Acceptable Documents; Acceptable Printing Paper

11
Document/Printing Paper Specification
s
Acceptable Documents
s
Acceptable Printing Paper
Before Use
1.
2Weight : Sheet documents, books, etc, not exceeding 10kg.
2Size : 297mm x 432mm [max].
¡
Document glass plate
2Document thickness : 64gsm to 128gsm
2Document size : 297mm x 432mm [max].
100mm x 148mm [min].
2Stacking capacity in document tray : 100 sheets ( 64gsm )
The following types of document cannot be used:
2
Documents with large file-binding holes, tears, or missing parts
2
Documents with staples or paper clips attached
2
Documents with markedly curling ends/sides, or marked folds
2
Carbon-backed documents
2
Sticky documents
2
Highly transparent documents such as OHP film
When ADF is Installed:
2
To make a new plate from a document from which a plate has already
been made, remove and then reload the document.
2
Always use documents of the same size.
2
If you load documents of different lengths, the printer may not operate
correctly.
IMPORTANT
:
IMPORTANT
:
¡
ADF
2Paper thickness : 53 gsm to 210 gsm (13 lb to 110 lb)
2
Paper size : 297mm x 432mm [max].
100mm x 150mm [min].
2
Paper stacking capacity: Feed tray : 1500 sheets ( 64gsm high-grade paper )
Print tray : 1500 sheets ( 64gsm high-grade paper )
The following types of paper cannot be used.
2
Paper with large file-binding holes
2
Paper with staples or paper clips attached
2
Paper with markedly curling ends/sides, or marked folds
2
Carbon-backed paper
2
Paper with smaller pieces of glued paper
IMPORTANT
:
¡
Feed tray / Print tray
