105
Removing the Drum Unit
5
When the message “NO DRUM” is displayed on
the LCD panel, use the following procedure to
replace the drum.
"
Do not touch the drum surface. Ink may
transfer to your clothes.
"
Hold the drum level and place it on a
flat,solid surface.
IMPORTANT
:
4
Grip the “upper drum shaft” with your other
hand, and pull the drum out toward you while
slightly lifting the near end of the “drum”.
s
How to Install the Drum Unit
1
Hold the “drum” level and place the “drum
guide roller” onto the “rail” in the machine.
Roller
440018a
2
Release the “upper drum shaft” and press the
“drum” in about 10cm while lifting up the front
end slightly.
440019
Installing the Drum Unit
When the message “NO DRUM” is displayed on the LCD panel, use the following procedure to replace
the drum.
Rail
440017-1
Drum
Replacement
5.
Grip from below the
upper drum shaft
To Next Page
